Great little speaker. Old style construction which I love.
My original speaker bought the farm. Now sounding better than ever with this speaker.
Brought new character to my '65 Vibro Champ.
Made my 1958 Fender 5F1 come alive
Wow! Great sounding little speaker, actually a lot better that I was expecting! I installed it in a 1966 Fender Champ that hadn’t worked in almost 40 years. The original speaker was dry rotted, after replacing several capacitors and installing this speaker it is sounding fantastic. This speaker doesn’t sound like an 8” speaker.
Orders have a lead time of approximately 1 week to ship.
Jupiter 8SC is an 8" seamed cone speaker with a small ceramic motor, an upgrade replacement for Jensen C8R.
See Video below: 8SC Ceramic vs. 8SA Alnico
Dimensions:
-Diameter: 8 3/16"
-Depth rear mount: 3 1/2"
-Cut-out hole diameter:
7 3/16”
-Mounting Holes: .18"x.3"
-Number of mounting holes: 4
-Mounting Hole Circle Diameter: 7 3/4"
Specs:
-Power Handling: 25W
-Sensitivity: 94.5 dB
-Voice Coil Diameter: 1"
-Magnet: Small Ceramic - 20oz
-Weight: 2.65lbs
Speaker Type Magnet
|
Voice Coil
Diameter
|
Headroom - Clean |
Break-up |
SC
|
1"
|
Low |
Early |
SA
|
1"
|
Low |
Early |
MC
|
1.5"
|
Yes - medium/high |
Clean - Slight Compression |
MA
|
1.5"
|
Yes - medium/high |
Clean - Slight Compression |
LC
|
1.5"
|
Yes - Clean Headroom |
Lots of Clean Headroom |
LA
|
1.5"
|
Yes - Clean Headroom |
Lots of Clean Headroom |
